3D Solid Modeling
This module adds 3D solid modelling tools to the nanoCAD 26 Platform. With it, you can create 3D parts, put them together into assemblies, and design sheet metal components.
There are two ways to model: direct editing (push, pull, and reshape solid objects by hand) and parametric modelling (define your design with dimensions and rules, so changes update automatically).
Your 2D documentation drawings stay linked to the 3D model. When you change the model, the drawings update to match.
- No commitment
- All modules included in trial
- Pay in ZAR
3D Solid Modeling capabilities
What you can do
- Build solid 3D parts using direct and parametric methods
- Assemble parts together using 3D constraints (rules that lock parts in position relative to each other)
- Design sheet metal components (flat patterns, bends, flanges)
- Sketch on the faces of 3D objects using dynamic UCS
- Create 2D drawings that stay linked to your 3D model
3D Solid Modeling Pricing
Get the 3D Solid Modeling Module
R 198
per year as a standalone module add-on
This module requires the nanoCAD 26 Platform. 30-day free trial is available with all modules included.
3D Solid Modeling Bundles
Also included in these bundles
Save by purchasing a bundle that includes this module with the nanoCAD 26 Platform.
Request a Quote
Request a quote for 3D Solid Modeling
Ready to buy 3D Solid Modelling?
Get a free 30-day trial with all modules included. Or request a quote for pricing.
