Construction

This module adds tools for architectural and construction drawing to the nanoCAD 26 Platform.

It includes libraries of ready-made building components – things like walls, doors, windows, columns, and structural elements – that you can place and adjust quickly instead of drawing each one from scratch.

The module supports IFC files. IFC (Industry Foundation Classes) is a file format used to share building models between different design and construction software. This makes it easier to work with other teams who use BIM (Building Information Modelling) tools.

Construction capabilities

What you can do

Create architectural plans, sections, and elevations
Place ready-made building components from built-in libraries
Generate construction documentation from your designs
Open and save IFC files for sharing with BIM software
Create standard construction details

Construction Pricing

Get the Construction Module

R 198

per year as a standalone module add-on

This module requires the nanoCAD 26 Platform. 30-day free trial is available with all modules included.

Construction Bundles

Also included in these bundles

Save by purchasing a bundle that includes this module with the nanoCAD 26 Platform.

nanoCAD Construction

nanoCAD 26 Platform + Construction Module

nanoCAD Max

nanoCAD 26 Platform + All 5 Modules

Request a Quote

Request a quote for Construction

Ready to try Construction?

Get a free 30-day trial with all modules included. Or contact SolidCAD for pricing.
