Mechanica
This module adds mechanical design tools to the nanoCAD 26 Platform. It’s built for engineers who design mechanical parts and assemblies.
It comes with a library of ready-made standard parts – things like bearings, fasteners, gears, shafts, and springs. Built-in calculators help you size these parts correctly, following ISO and other international engineering standards.
The module also reads IDF files. IDF is a format used by electronics design (ECAD) software to share board shapes and component positions, which is useful when designing enclosures or housings for electronic products.
- No commitment
- All modules included in trial
- Pay in ZAR
Mechanica capabilities
What you can do
- Create 2D and 3D mechanical drawings
- Use ready-made standard parts from the built-in library
- Size gears, shafts, springs, and other components using built-in calculators (ISO-compliant)
- Import board outlines from electronics design software (IDF format)
- Apply 2D and 3D constraints to control your design
- Link 2D documentation to 3D models
Mechanica Pricing
Get the Mechanica Module
R 198
per year as a standalone module add-on
This module requires the nanoCAD 26 Platform. 30-day free trial is available with all modules included.
Mechanica Bundles
Also included in these bundles
Save by purchasing a bundle that includes this module with the nanoCAD 26 Platform.
Request a Quote
Request a quote for Mechanica
Ready to try Mechanica?
Get a free 30-day trial with all modules included. Or request a quote for pricing.
